Number of Index Tool stations
4pcs (max. 24 pcs)
Max. punch diameter 89 mm
Max. tool rotation 58 r/min
Max. material thickness 6.35 mm
Max. sheet weight (1) 200 kg
Clamps pneumatic 3 pcs
Max. sheet size (X x Y) 2530 mm x 1270 mm
X traverse 2584 mm (X-42 ... X2542)
Y traverse 1317 mm (Y-25 ... Y1292) |
